Kirloskar Ha694tc

Name: Kirloskar Ha694tc
Brand: KY ENTERPRISE
Price: 350000.00 INR
Availability: InStock

Price 350000.00 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Kirloskar Ha694tc Specification

Engine Type
4 Stroke, Turbocharged

Poles Number
4 pole

Protection Class
IP23

Standard
Conforms to IS/IEC 60034-1

Bore *Stroke
160mm x 200mm

Pressure
18.0 bar (injection pressure)

Fuel Consumption
Approx. 120 Ltr/hr at 100% load

Fuel Tank Capacity
Approx. 900 Litres

Dimension (L*W*H)
Approx. 5500mm x 2200mm x 2700mm

Engine Model
HA694TC

Alternator
Brushless, Synchronous

Insulation
Class H

Product Type
Diesel Generator

Output Type
AC Three Phase

Rated Power
625 kVA

Rated Voltage
415 V

Starting Type
Electric Start

Rated Frequency
50 Hz

Power Range
625 kVA / 500 kW

Color
Beige and Black

Cooling System
Water Cooled

Noise Level
Silent (Soundproof Canopy)

Phase
Three Phase

Speed
1500 RPM

Weight
Approx. 6500 kg

Mounting
Skid Mounted

Vibration
Anti-vibration mounts provided

Ambient Temperature
Up to 50C

Relative Humidity
Up to 95% (non-condensing)

Exhaust System
Industrial Silencer Included

Alternator Efficiency
Above 92%

Governor Type
Electronic Governor

Regulation
1% Voltage regulation

Control Panel Type
Digital Automatic Mains Failure (AMF) panel

Lubrication System
Forced lubrication with oil cooler

Emissions
CPCB II compliant

Battery Capacity
2 x 180Ah, 12V each

Fuel Type
HSD (High Speed Diesel)

About Kirloskar Ha694tc

Kirloskar Silent & Open Diesel Generators

Power Range: 5 kVA to 3000 kVA
Phase: Single & Three Phase
Country of Origin: Made in India

Product Overview

Experience uninterrupted power and trusted performance with Kirloskar Diesel Generators Indias most reliable and efficient power solutions.

Kirloskar Silent Generators are equipped with acoustic enclosures for noise-free operation, while Open Type Generators are designed for heavy-duty industrial applications.
Whether for home backup or commercial power, Kirloskar gensets ensure stable voltage, consistent frequency, and long-lasting durability maximizing uptime and protecting your equipment.

Key Features & Benefits

High Reliability: Powered by robust Kirloskar engines engineered for long life and consistent performance.

Silent Operation: Acoustic canopy meets CPCB IV+ standards for low noise levels.

Fuel Efficiency: Advanced fuel injection system minimizes fuel consumption and maximizes savings.

Heavy-Duty Design: Strong alternators, anti-vibration mounts, and durable construction for long-term performance.

Smart Control Options: Available with Manual, AMF (Auto Mains Failure), and Remote Monitoring systems.

Eco-Friendly: CPCB IV+ compliant engines ensure low emissions and cleaner performance.

Easy Portability: Compact canopy with lifting hooks, skid base, and simple mobility options.

Advanced Safety Features: Includes oil pressure sensor, water temperature indicator, circuit breaker, and emergency stop function.

Applications: Ideal for homes, offices, hospitals, industries, showrooms, construction sites, and agricultural use.

Available Models & Applications

Kirloskar Silent Diesel Generators (With Acoustic Enclosure)

15 kVA Silent DG Set: Compact model for homes, shops, and small offices.

25 kVA to 62.5 kVA: Suitable for showrooms, schools, clinics, and small industries.

82.5 kVA to 125 kVA: Ideal for mid-sized businesses, hotels, and commercial complexes.

160 kVA to 250 kVA: Perfect for large offices, hospitals, and manufacturing units.

320 kVA to 500 kVA: Reliable power for factories and infrastructure projects.

600 kVA to 1010 kVA: Heavy-duty models for data centres, large industries, and institutions.

Kirloskar Open Type Diesel Generators

15 kVA to 250 kVA: Cost-effective, easy-maintenance gensets for industrial and construction applications.

Technical Highlights

Specification	Details
Engine Type	Kirloskar CPCB IV+ Compliant Diesel Engine
Starting System	Manual / Electric Start / AMF Panel
Cooling System	Water-Cooled / Air-Cooled (as per model)
Alternator Type	Brushless, Self-Excited, High Efficiency
Frequency	50 Hz / 60 Hz
Voltage	230V (Single Phase) / 415V (Three Phase)
Insulation Class	H Class (High Protection)
Canopy Design	Powder-Coated, Weather & Sound Proof
Fuel Tank Capacity	Long-run diesel tank for extended backup
Warranty	1 Year on DG Set / 2 Years on Engine (model-based)

Why Choose Kirloskar Generators?

India leading and trusted generator brand.

Low maintenance with nationwide service support.

Superior fuel efficiency for maximum cost savings.

Environment-friendly design with low noise and emissions.

Built for 24x7 continuous heavy-duty operation.

Ready stock available with fast delivery and installation across India.

Why Choose KY Enterprise?

Authorized and experienced Kirloskar & Cummins supplier.

Quick response and prompt after-sales support.

Wide range of genuine engines, gensets, and spare parts.

Customer-focused approach ensuring complete satisfaction.

Contact Us

For quotations, product catalogues, and expert guidance.

KY Enterprise: Powering Performance with Genuine Kirloskar Solutions.

Optimized for Performance and Efficiency

The Kirloskar HA694TC combines a high-efficiency alternator (over 92%) with a four-pole, brushless, synchronous design. It operates at 1500 RPM, maintaining steady voltage and frequency under diverse loads, making it perfect for industrial and commercial use. Its forced lubrication system with oil cooling enhances engine life and reliability.

Silent and Environmentally Friendly Operation

Outfitted with a soundproof canopy, industrial silencer, and meeting CPCB II emission norms, this generator ensures minimal noise and reduced environmental impact. Its advanced exhaust and cooling systems help the generator perform effectively even in challenging ambient conditions, maintaining compliance with the latest standards.

Advanced Control and Seamless Integration

The Digital AMF panel offers automatic start/stop and monitoring during power failures, ensuring uninterrupted operations. The generator's anti-vibration mounts and skid mounting simplify installation while promoting operational safety and reducing wear over time.

FAQ's of Kirloskar Ha694tc:

Q: How does the Kirloskar HA694TC ensure stable power output?

A: The generator maintains a consistent output with its electronic governor, 1% voltage regulation, and a high-efficiency (above 92%) brushless synchronous alternator. This ensures reliable AC three-phase supply, ideal for sensitive industrial and commercial equipment.

Q: What are the advantages of the forced lubrication system with oil cooler?

A: The forced lubrication system with integrated oil cooler maintains optimal engine temperature and minimizes wear. This results in better engine lifespan, improved efficiency, and reduced maintenance frequency, especially during prolonged heavy-duty operations.

Q: Where can the Kirloskar HA694TC be installed?

A: With its anti-vibration mounts, skid-mounted design, and IP23 protection class, the generator can be installed in varied industrial premises, outdoor areas, or manufacturing units across India, even in environments with up to 95% relative humidity and temperatures up to 50C.

Q: How does the Digital Automatic Mains Failure (AMF) panel enhance usage?

A: The Digital AMF panel automates generator startup during mains failure and shutdown upon power restoration. It also offers advanced monitoring and control features, reducing manual intervention and ensuring a continuous power supply.

Q: What benefits does the soundproof canopy provide?

A: The soundproof canopy significantly reduces operational noise, ensuring silent operation. This allows for installation in noise-sensitive environments, improving comfort and compliance with local noise regulations.

Q: When should regular maintenance be carried out on the HA694TC?

A: Regular maintenance, including checking oil, coolant, filters, and battery health, should follow the manufacturer's recommended schedule-typically, after every set number of operational hours or as specified in the service manual for optimal performance and longevity.
