Kirloskar Generator 5kv

Name: Kirloskar Generator 5kv
Brand: KY ENTERPRISE

Get a Price/Quote

MOQ : 1 Unit

Kirloskar Generator 5kv Specification

Fuel Consumption
1.5 ltr/hr @ 75% load

Poles Number
4 Pole

Engine Model
Kirloskar HA194

Engine Type
4 Stroke, Naturally Aspirated

Fuel Tank Capacity
65 Litres

Alternator
Brushless, Self Excited

Standard
Complies with ISO 8528 & CPCB II norms

Bore *Stroke
87.5 mm x 110 mm

Protection Class
IP23

Dimension (L*W*H)
1850 x 900 x 1160 mm (approx.)

Pressure
Compression Ignition

Insulation
Class H

Product Type
Generator

Output Type
AC Three Phase / Single Phase

Rated Power
5 kVA

Rated Voltage
230V / 415V

Starting Type
Electric Start

Rated Frequency
50 Hz

Power Range
5 kVA

Color
White & Grey

Cooling System
Air Cooled / Water Cooled

Noise Level
Silent (compliant with CPCB II norms)

Phase
Single / Three Phase

Speed
1500 RPM

Weight
Approx. 450 kg

Altitude Capability
Up to 1000 meters without derating

Service Interval
250 hours or 6 months

Control System
Microprocessor based auto start/stop

Efficiency
Above 90% full load efficiency

Overload Protection
Auto shut down with alarm

Display Panel
Digital (for current, voltage, frequency, hours run)

Fuel Type
High-Speed Diesel (HSD)

Operation Mode
Continuous & Standby use

Battery Capacity
Exide 12V, 88 Ah (included)

Applications
Ideal for offices, homes, small industries, and commercial usage

Enclosure
Soundproof, weatherproof canopy

Emission Compliance
Meets latest CPCB II Emission Norms

Lubrication System
Forced Lubrication

About Kirloskar Generator 5kv

Kirloskar Silent & Open Diesel Generators

Power Range: 5 kVA to 3000 kVA
Phase: Single & Three Phase
Country of Origin: Made in India

Product Overview

Experience uninterrupted power and trusted performance with Kirloskar Diesel Generators Indias most reliable and efficient power solutions.

Kirloskar Silent Generators are equipped with acoustic enclosures for noise-free operation, while Open Type Generators are designed for heavy-duty industrial applications.
Whether for home backup or commercial power, Kirloskar gensets ensure stable voltage, consistent frequency, and long-lasting durability maximizing uptime and protecting your equipment.

Key Features & Benefits

High Reliability: Powered by robust Kirloskar engines engineered for long life and consistent performance.

Silent Operation: Acoustic canopy meets CPCB IV+ standards for low noise levels.

Fuel Efficiency: Advanced fuel injection system minimizes fuel consumption and maximizes savings.

Heavy-Duty Design: Strong alternators, anti-vibration mounts, and durable construction for long-term performance.

Smart Control Options: Available with Manual, AMF (Auto Mains Failure), and Remote Monitoring systems.

Eco-Friendly: CPCB IV+ compliant engines ensure low emissions and cleaner performance.

Easy Portability: Compact canopy with lifting hooks, skid base, and simple mobility options.

Advanced Safety Features: Includes oil pressure sensor, water temperature indicator, circuit breaker, and emergency stop function.

Applications: Ideal for homes, offices, hospitals, industries, showrooms, construction sites, and agricultural use.

Available Models & Applications

Kirloskar Silent Diesel Generators (With Acoustic Enclosure)

15 kVA Silent DG Set: Compact model for homes, shops, and small offices.

25 kVA to 62.5 kVA: Suitable for showrooms, schools, clinics, and small industries.

82.5 kVA to 125 kVA: Ideal for mid-sized businesses, hotels, and commercial complexes.

160 kVA to 250 kVA: Perfect for large offices, hospitals, and manufacturing units.

320 kVA to 500 kVA: Reliable power for factories and infrastructure projects.

600 kVA to 1010 kVA: Heavy-duty models for data centres, large industries, and institutions.

Kirloskar Open Type Diesel Generators

15 kVA to 250 kVA: Cost-effective, easy-maintenance gensets for industrial and construction applications.

Technical Highlights

Specification	Details
Engine Type	Kirloskar CPCB IV+ Compliant Diesel Engine
Starting System	Manual / Electric Start / AMF Panel
Cooling System	Water-Cooled / Air-Cooled (as per model)
Alternator Type	Brushless, Self-Excited, High Efficiency
Frequency	50 Hz / 60 Hz
Voltage	230V (Single Phase) / 415V (Three Phase)
Insulation Class	H Class (High Protection)
Canopy Design	Powder-Coated, Weather & Sound Proof
Fuel Tank Capacity	Long-run diesel tank for extended backup
Warranty	1 Year on DG Set / 2 Years on Engine (model-based)

Why Choose Kirloskar Generators?

India leading and trusted generator brand.

Low maintenance with nationwide service support.

Superior fuel efficiency for maximum cost savings.

Environment-friendly design with low noise and emissions.

Built for 24x7 continuous heavy-duty operation.

Ready stock available with fast delivery and installation across India.

Why Choose KY Enterprise?

Authorized and experienced Kirloskar & Cummins supplier.

Quick response and prompt after-sales support.

Wide range of genuine engines, gensets, and spare parts.

Customer-focused approach ensuring complete satisfaction.

Contact Us

For quotations, product catalogues, and expert guidance.

KY Enterprise: Powering Performance with Genuine Kirloskar Solutions.

Advanced Digital Control and Display

Monitor essential parameters with the clear digital display panel, including current, voltage, frequency, and running hours, ensuring real-time awareness of generator performance. The microprocessor-based auto start/stop system provides seamless operation and simplifies user interaction, making it suitable even for those without technical experience.

High Efficiency and Low Fuel Consumption

With above 90% efficiency at full load and fuel consumption at only 1.5 litres per hour (at 75% load), the Kirloskar Generator is designed for cost-effective power solutions. This ensures optimal energy use whether for continuous or standby operation, reducing overall operational costs for your home or business.

Reliable and Safe Operation

Safety and reliability are prioritized with automatic overload protection that triggers shutdown and alarm, soundproof and weatherproof canopy for low noise and prolonged lifespan, and compliance with ISO 8528 and CPCB II emission norms. Users benefit from continuous power supply and safer working environments, even in demanding conditions.

FAQ's of Kirloskar Generator 5kv:

Q: How does the microprocessor-based auto start/stop system work in the Kirloskar 5kVA generator?

A: The microprocessor-based control system automatically manages the generator's start and stop operations, responding to your power needs and protecting the generator during overloads or faults. This minimizes manual intervention and increases overall convenience and safety.

Q: What benefits does the digital display panel provide on this generator?

A: The digital panel shows real-time data for current, voltage, frequency, and hours run, allowing users to easily monitor performance, schedule maintenance efficiently, and ensure optimal operation, reducing downtime and maintenance errors.

Q: When should I schedule service for the Kirloskar Generator 5kVA?

A: Scheduled maintenance is recommended every 250 running hours or every 6 months, whichever occurs first. Regular servicing keeps the generator operating efficiently and prolongs its lifespan.

Q: Where can the Kirloskar Generator 5kVA be ideally used?

A: This generator is perfect for offices, homes, small industries, and commercial applications. Its soundproof, weatherproof enclosure enables usage in both indoor and outdoor environments, even in demanding weather conditions.

Q: What is the process to start the generator and ensure safe operation?

A: Starting the generator involves simply using the electric start feature. The auto start/stop system and overload protection ensure that the generator operates safely, automatically shutting down and alerting you if it encounters excessive loads or malfunctions.

Q: How does fuel efficiency impact the overall usage cost?

A: Since the generator consumes only 1.5 litres per hour at 75% load and maintains above 90% efficiency at full load, it significantly reduces fuel expenses over time-especially during prolonged or frequent operation.

Q: What are the main benefits of choosing the Kirloskar 5kVA generator for my power needs?

A: This generator offers reliable performance, automatic safety features, silent operation, easy monitoring, and low running costs. It complies with stringent emission standards and provides flexibility in phase options, ensuring efficient power supply for diverse applications.
